Single pole breaker thermal BLUE SEA 25 A

Single pole thermal type breaker:

This circuit breaker is particularly recommended for protection of windlasses, capstans, engines bridges etc...

Protected against water and gasoline vapors, it can be mounted in machine rooms and the shims.

This circuit breaker can be used as a switch, its rearmament after trigger is manual.

Technical characteristics :

• Model recessed
• 25A
• Maximum operating voltage: 48 VDC
• Trigger type: thermal
• Breaking capacity: 12V: 5 kA - 24V: 3 kA
• Safety interlocking: impossible circuit overload or short circuit.
• Material: phenolique
• IP66
