Controller batteries 1 Park XANTREX Link Pro

Controls the voltage and intensity of your batteries.

-Display of the remaining time in A.h

-Resolution of the finer measures

-Input for optional temperature sensor

-Communication port (optional history processing software)
-Internal memory registers a large number of data on the use of the battery as:
-Average the depth of discharge
-The number of charge/discharge cycle
-The number of high and low voltage alarm

-Voltage 1 or 2 Battery Park

-Charge current / discharge 1 Battery Park

-Bar graph the battery status

-Consumed A.h
-Alarms programmable low/high battery voltage + dry contact 1A max. for generator start / stop of consumer
-Battery capacity: 20-9999 Ah
-Power supply: 9-35 V
-Consumption: 9 my under 12V
-Front waterproof to splash water
-Shunt 500 A / 50 mV provided
-Installation: drill + screwing on ring
-Façade diam. 64mm / depth 72.5 mm / hole diam. 92 mm
